PURE-AIR first introduces the dry dust removal method in smoking absorber fume extractor solder. After understanding the method, you will know why it is needed.

Dry dust removal equipment: When the dust-containing gas enters the dust hopper of the dust collector from the air inlet, it first encounters the baffle in the air inlet pipe, and the airflow rotates upward. At the same time, the airflow speed slows down. Due to the effect of inertia, the coarse particle dust in the gas directly falls into the ash hopper, which plays the role of pre-collecting dust. The upward rotating dust catches the dust on the outer surface of the filter bag through a filter bag with a metal frame inside. The purified gas enters the clean room and is collected in the air outlet pipe for discharge. When the dust is removed, the compressed air blowback system is activated, and the compressed air is blown out from the filter bag to make the dust fall into the ash hopper. solder fume extraction

Controlled by a solenoid valve, the filter bags arranged in a certain order remove dust in turn. Electrostatic precipitator technology is a technology that uses the strong field generated by high-voltage electricity to ionize gas, that is, corona discharge is generated, the dust is charged at close range, and the suspended particles in the gas are separated under the action of the electric field force. Its advantages are high dust removal efficiency, low resistance loss, and a rich classification of smoke and dust of different particle sizes. Filter bag dust removal uses filter materials to filter dust-containing gas to achieve the purpose of dust removal resistance.

The above content answers the principle of solder fume extractor filter dust removal in detail, and we can also see the development of dust removal technology. In the future, more advanced dust removal technologies will be born.

If you want buy fume extractor, please contact with Dongguan Pure-Air Tech Co.,ltd, E-mail: sales@pure-airtech.com.
