product details
Working principle
The high-performance brushless fan generates negative pressure, sucks smoke and exhaust gas into the purifier, and then discharges it after purification by a multi-stage filter.
Features and benefits
Small body, low running noise, casters installed, easy to move;
Low power consumption, maintenance-free brushless fan, stable operation and long service life;
It can realize air volume adjustment, LCD display screen can check the air volume and gear of the machine in real time;
The control system has a filter clogged alarm function, prompting to replace the filter in time;
Equipped with a wireless remote control to facilitate remote operation of the machine. Can also configure remote linkage start-stop interface;
Multi-stage large-capacity filters to ensure efficient purification of smoke, odor and harmful gas;
Smoke and dust filtering efficiency is up to 99.7%@0.3 microns (self-tested by our company), which can be discharged indoors;
The filter element can be replaced separately, which reduces the use cost of the filter element, and it is more convenient to maintain and replace the filter element;
Stainless steel cabinet can be customized according to customer requirements.
Product parameter
Model
|
PA-400FS-HP-IQ
|
PA-500FS-HP-IQ
|
PA-1000FS-HP-IQ
|
PA-1500FS-HP-IQ
|
Max Air Flow
|
400 m3/h
|
500 m3/h
|
1000 m3/h
|
1500 m3/h
|
Max Pressure
|
9600 Pa
|
9600 Pa
|
9600 Pa
|
9600 Pa
|
Input Power
|
1.1 KW
|
1.1 KW
|
2.1 KW
|
3.0 KW
|
V / F
|
110V - 220V, 50-60HZ
|
Filter Type
|
F5 Filter pad (350*400*20mm)
|
F5 Filter pad (400*500*20mm)
|
F8 deep pleat filter (410*410*300mm)
|
F8 deep pleat filter (500*600*300mm)
|
H13 deep pleat filter (403*403*50mm)
|
H13 deep pleat filter (493*593*50mm)
|
Gas filter (410*410*140mm)
|
Gas filter (500*600*140mm)
|
Noise
|
≦65 dBA
|
≦66 dBA
|
≦68 dBA
|
≦70 dBA
|
Machine Size
|
475*577*1081mm
|
670*770*1203mm
|
Net Weight
|
75 kg
|
115 kg
|
117 kg
|
119 kg
|
Inlet Diameter
|
75 mm / 100 mm
|
75 mm /100 mm
|
100 mm /125 mm
|
150 mm /200 mm
|
Applications
3D printing of metal materials, composite materials, etc.
