The high-performance brushless fan generates negative pressure, sucks smoke and exhaust gas into the purifier, and then discharges it after purification by a multi-stage filter.
inquiry

Prev

  • Fume Extractor
  • Fume Extractor
  • Fume Extractor
  • Fume Extractor

Next

product details
Fume Extractor-3

PA-300TD-IQ

Fume Extractor

PA-300TS-IQ

Fume Extractor-4

PA-500TD-IQ

Fume Extractor-1

PA-500TS-IQ

Working principle

The high-performance brushless fan generates negative pressure, sucks smoke and exhaust gas into the purifier, and then discharges it after purification by a multi-stage filter.

Features and benefits

Small body, low running noise, equipped with casters, easy to move;

TS-IQ, TD-IQ, FS-IQ series are equipped with low power consumption, maintenance-free, large air volume brushless fans, stable operation and long service life. TS-LD-HP-IQ series is equipped with high negative pressure brushless fan, with large suction power;

It can realize air volume adjustment, LCD display can check the air volume and gear of the machine;

The control system has a filter clogged alarm function, prompting to replace the filter in time;

Equipped with a wireless remote control to facilitate remote operation of the machine. Can also configure remote linkage start-stop interface;

Multi-stage large-capacity filters to ensure efficient purification of fumes, odor and harmful gases. Can be equipped with special filter element to purify fumes and harmful gas from PVC material;

Smoke and dust filtering efficiency is up to 99.7%@0.3 microns (self-tested by our company), which can be discharged indoors;

The filter element can be replaced separately, which reduces the use cost of the filter element, and it is more convenient to maintain and replace the filter element;

Stainless steel cabinet can be customized according to customer requirements.

Product parameter
Model PA-150TS-IQ PA-300TS-IQ PA-300TD-IQ PA-500TS-IQ PA-500TD-IQ
Max Air Flow 150 m3/h 300 m3/h 2*150 m3/h 500 m3/h 2*250 m3/h
Max Pressure 2000 Pa 2500 Pa 3200 Pa
Input Power 0.08 KW 0.2 KW 0.35 KW
V / F 110V / 220V,50-60HZ
Filter Type F5 Filter pad (190*190*20mm) F5 Filter pad (180*350*20mm)
F8 deep pleat filter (190*190*50mm) F8 deep pleat filter (180*350*50mm)
H13 deep pleat filter + Gas filter (200*200*200mm) H13 deep pleat filter + Gas filter(190*360*210mm)
Noise ≦51 dBA ≦55 dBA ≦56 dBA ≦60 dBA ≦62 dBA
Machine Size 240*380*257mm 250*430*412mm 310*520*515mm
Net Weight 10 kg 15 kg 17 kg 22 kg 24 kg
Inlet Diameter 50 mm 50 mm / 75 mm
Applications

laser marking, engraving, scribing, coding, etc.
