Pure-Air air cleaner for laser machine&laser cleaning filter systems has a purification efficiency of 99.7% and a minimum filtration accuracy of 0.1UM. It is mainly used in the collection and purification of centralized smoke. Stand-alone specifications (processing air volume). If customers have special requirements, we will also design professionally for you. The maximum design processing air volume of a single machine is 16000m3/h.
Working principle of BG industrial heat treatment hardware processing oil fume purifier
Dust purifier, filter cartridge dust removal is based on the principle of the attraction of opposite sexes of charges, and the application of high voltage 10KV-16KV direct current to form two electric fields with opposite polarities. Under the action of Coulomb force, the oil fume particles are charged and moved to the dust collecting plate. It is attached to the collecting plate by the force of repulsion to achieve the purpose of purifying the air.
Pure-Air laser machine fume extraction uses narrow-pitch dual-zone collectors. Its dual zone refers to the ionization section and the collection section. Each ionization section is composed of a series of tungsten steel wires, which are connected to a high-voltage direct current in the middle of a series of grounding plates. The particles in the atmosphere are passed through the strong electrostatic field of the ionizer. Ionize and carry a positive or negative charge. Each collection section is composed of a large number of parallel plates, which are connected with high-voltage direct current (the polarity is the same as that of the ionizer, but the voltage is halved) to form an electric field. The charged particles are attracted by the ground plate and are driven by the charged plate at the same time. , When the airflow contains charged particles, it can be efficiently removed.
Efficient: Efficiently capture soot particles of different sizes, high purification efficiency, and fundamentally solve the problem of pollution transfer. To
Flexible: Modular purification units can be combined flexibly, and the number of units can be adjusted adaptively according to different purification treatment capacity and purification rate requirements.
Advanced: The electrostatic power control system can automatically adjust the intensity of the electric field, so that the purification equipment can maintain a high purification rate after long-term operation.
Safety: The safety system is well-designed, the high-voltage power supply is automatically cut off when the inspection door is opened; the high-voltage power supply is carefully designed into a unit body sealed by epoxy resin, which is safe and reliable to use
Stability: The electrostatic power supply control system has an automatic over-current and over-voltage protection device to ensure the stable operation of the equipment.
Economy: Long service life, energy saving and high efficiency, and small floor space. We supply industrial dust purifiers to ensure that the equipment provided is brand new, complete, and unused, and all technical data (instructions/warranty sheets) accompanying the equipment are complete. Ensure that the dust purifier is reliable and operating normally. After purification, the dust reaches the national environmental protection standard, and the emission concentration is ≤2.0mg/m3.
If you want to buy laser fume extractor, please contact with
‘Dongguan Pure-Air Tech Co.,Ltd.’.
