Pulse dust collector with high dust collection efficiency, cabinet dust collector-industrial production dust solution, dust collector equipment-the structure of the sinking filter cartridge fume extractor is composed of air inlet and ventilation ducts, exhaust system pipes, and cyclone separation. It is composed of plate, ash removal chamber, filter cartridge module, air storage bag, pulse solenoid valve, pulse controller, net brake air chamber, collection bin, etc., similar to the single pulse bag ash removal structure of the dust collector.

Due to the effect of the negative pressure cyclone, the smoke and dust vapor enters the dust removal body from the channel of the pulse dust collector and the cabinet vacuum cleaner. According to the filtering effect of the filter cartridge, the dust is extracted from the cyclone and is cleaned and cleaned. The steam enters the net brake air chamber from the inside of the filter cartridge and is discharged; when the dust passes through the filter cartridge, the dust remains on the outer surface of the filter cartridge.

When the pulse fume extractor and cabinet vacuum cleaner are cleaning dust, the pulse controller sends a command to open each pulse solenoid valve in order, so that the air in the air bag is compressed from the holes of the injection boiler blowpipe to the matching venturi Inside the nozzle (called primary air). When the high-speed cyclone is based on the Venturi nozzle, it induces multiple times the surrounding air (called secondary air) of the primary wind to enter the filter cartridge, causing the filter cartridge to swell sharply in an instant. Because of the reverse effect of the cyclone, the dust accumulated on the filter cartridge will fall off. After the pulse solenoid valve is turned off, the cyclone in the opposite direction will be caused again, causing the filter cartridge to contract rapidly, causing one expansion and contraction, resulting in the expansion and contraction of the filter cartridge. , The foundation accumulated on the outside of the filter cartridge falls down due to the effect of inertia, which upgrades the filter cartridge, and the removed dust falls into the silo under the dust collector.

If you want buy fume extractor, please contact with Dongguan Pure-Air Tech Co.,ltd,
