The application of laser cutting machines is becoming more and more popular
in the production of daily necessities. How to efficiently use laser cutting
technology to produce processed products requires the operator of the laser
cutter to have a good understanding of each and learn relevant professional
knowledge, and more importantly, to continuously summarize experience in
practice. Below, the PURE-AIR laser cutting smoke filter manufacturer will
analyze several commonly used laser cutting technical parameters for you.
To reduce the change of the focal spot size caused by the change of the
beam size before the focus, many manufacturers of laser cutting equipment at
home and abroad provide special devices for users to choose:
The laser collimator. This is a commonly used method on laser machines,
that is, add a collimator to the output end of the CO2 laser for beam expansion.
After the beam expands, the diameter of the beam becomes larger and the
divergence angle becomes smaller, so that the near end is within the cutting
working range It is close to the same size as the beam before the far end
focus.
Add an independent lower axis of the moving lens to the laser head of the
laser cutting machine, which is independent of the Z axis that controls the
distance from the nozzle to the material surface. When the machine tool table
moves or the optical axis moves, the beam moves from the proximal end to the
distal F axis at the same time, so that the beam spot diameter remains the same
in the entire processing area after the beam is focused.
Control the water pressure of the laser focusing lens (usually a metal
reflective focusing system). If the beam size before focusing becomes smaller
and the focal spot diameter becomes larger, the water pressure is automatically
controlled to change the focus curvature to make the focal spot diameter
smaller.
