PURE-AIR laser fume extractor factory manufacturers share some tips for adjusting the parameters of laser marking machines to help laser marking companies operate more efficiently.

Laser power current-control the laser power value output by the laser. The greater the current value, the greater the laser power.

Frequency-control the peak power of the laser and the number of laser pulses per unit time. The larger the frequency value, the smaller the peak power and the more laser pulses per unit time.

Pattern filling spacing-control the degree of solidity in the marking figure. The smaller the graphic spacing, the denser the filling and the closer the graphic is to solid. Of course, the more lines, the longer the processing time. vice versa.

Filling angle-control the direction of the filling line and determine the lines in the graph. The common filling angles are: 0 degrees or 180 degrees; 90 degrees; 45 degrees; 135 degrees.

Marking speed of laser marking machine-control the speed of laser marking. It is the processing speed of the laser marking machine when marking-the speed of the laser output when marking the line. The speed of the laser when scanning the frame of the graphics; the speed of the laser from the initial point to the starting point of processing.

The parameters that do not need to be adjusted frequently are: the following effects mainly determine the line effect of the marking figure, such as line sealing, filling and overlap of the wheel, etc., generally the default is sufficient.

Light-on delay: the delay of the laser at the moment the laser outputs the laser. Turn-off delay: the delay of the laser at the moment when the laser is turned off. Corner delay: When the included angle is greater than 135 degrees, the delay of the laser at the corner. Jump delay: the delay between the laser turning off and on.

PURE-AIR has accumulated a lot of knowledge in laser-related industries in the process of research and development in cooperation with well-known laser marking companies. The laser smoke filter supporting these industry knowledge can better serve laser marking companies.

If you want to purchase fume extractor, please contact “DongGuan PURE-AIR Tech Co,Ltd.”Thank you.
