Welding dust collection equipment, a mobile stand-alone dust collector in the welding workshop, using a single Smoke and dust purifier to purify it is mainly used for the treatment of hand welding fume and dust in few stations. This equipment collects smoke and dust point to point. The equipment has 4 universal wheels for easy movement. Its main equipment includes Single arm welding fume purifier, double-arm welding fume purifier. Its main components are universal vacuum arm, high temperature resistant vacuum hose, vacuum hood (with air volume regulating valve), fire barrier, flame retardant high-efficiency components, pulse blowback device, pulse solenoid valve, differential pressure gauge, purification Chamber, activated carbon filter, dust box combination, flame-retardant sound-absorbing cotton, new Korean casters, blower, motor, control box, etc.

Principle of operation: The smoke and dust generated during work are sucked into the welding dust suction equipment through the suction hood, and the mobile stand-alone dust collector in the welding workshop, through the fire barrier of the purifier, first separates the large granular spark particles from the polished particles. The pre-filtered air enters the second-layer filter protection plate, and the protective plate diverges to prevent residual sparks from entering the third-layer main filter for purification. A single smoke and dust converter is equipped with one or two suction arms, and the base is equipped with four universal casters. It is used for the purification of the smoke and dust generated by the mobile welding station in various welding, grinding and other places, as well as the purification of rare metals and precious materials. Of recycling.

Dust removal meets national emission standards. It is a new type of welding dust collection equipment and a mobile stand-alone dust collector for welding workshops. The dust-containing gas enters the vacuum cleaner box from the suction port on the upper part of the vacuum cleaner. Under the influence of gravity and lower airflow, the dust-containing gas particles are first directly dropped into the ash hopper, and the fine dust-containing gas is captured by the outer surface of the filter cartridge to clean the gas. After being filtered and purified by the filter cartridge, it enters the clean room from the center of the filter cartridge and is discharged from the downwind vent. As the filtration continues, dust will accumulate on the surface of the filter cartridge. At this time, the pulse controller controls the opening of the solenoid valve according to the set pulse period and pulse interval, sprays high-pressure gas into the inner cavity of the filter cartridge, vibrates the external dust, and discharges the ash from the ash hopper. Filter cartridge dust collector has the advantages of small footprint, high purification efficiency, and no secondary pollution.

If you want buy fume extractor, please contact with Dongguan Pure-Air Tech Co.,ltd, E-mail: sales@pure-airtech.com.
