The appearance of the dust collector of PURE-AIR technology is characterized by a box-type cabinet structure, a large fan air volume, and a small footprint. It adopts an integrated customized chassis structure with a simple and elegant appearance. It is specially designed for carbon powder, graphite powder, cement powder, and flour. It is designed for the floating dust collection configuration with a large amount of dust, and it is perfectly integrated with the host. laser co2 fume extractor

Power system: using Siemens three-phase asynchronous motor, with three-phase 380V voltage, equipped with PURE-AIR special customized aluminum alloy impeller, the negative pressure and flow are excellent, the dust collector runs smoothly, the failure rate is low, the noise is low, and it can be 24 Work continuously and efficiently within hours.

Electrical system: The main electronic control components adopt the international famous brand-Schneider of France. Independent control of the electric box, built-in AC contactor, thermal overload protection, phase sequence protection such as phase loss and reverse phase, high safety. The control panel is simple and clear, and can easily realize the remote linkage control function. laser cutting air filter

Filter system: Use Japanese Toray polyester fiber substrate, high-efficiency PTFE membrane filter cartridge, high filtration accuracy. The standard configuration is polyester fiber oil-proof and waterproof material, and the filtering accuracy of dust with an equivalent diameter of 3 microns or more is more than 99%. A higher filtering accuracy filter cartridge material can be selected.

Self-developed dust removal technology: self-developed patented automatic rotary pulse back-blowing technology, the cleaning effect is 3 times higher than the traditional method, the pulse back-blowing system is composed of gas storage tank, solenoid valve, pulse controller, automatic rotation injection components, etc. laser cutting smoke extractor

When the pulse controller sends out a pulse signal, the solenoid valve starts to work. The high-pressure air sprayed out at a very high flow rate enters the inner wall of the filter cartridge through the automatic rotating blowing assembly, causing the filter cartridge to expand rapidly, causing shock and vibration, and causing the smoke and dust attached to the surface of the filter cartridge to be shaken off to the dust collecting drawer middle.

Dust collection box: The drawer type dust collection box is practical and convenient, in order to avoid manual cleaning of the outer surface of the filter cartridge, which will cause dust to splash around and form secondary pollution. The dust box adopts a drawer type structure. When there is a lot of dust accumulation, open the door, pull the dust box out to clean up the dust, and then send the dust box in after completion. Convenient, fast and practical.

Universal suction arm: Built-in skeleton, can hover at any position 360 degrees. The smoking hood adopts a large-scale mask design, which can suck the welding fumes with maximum efficiency; the suction arm hose is made of high-grade polyester material, which is fire-resistant and flame-retardant. Optional horseshoe shape, top hat shape, etc., can also be customized stainless steel material.

Quality casters: industrial casters, non-slip and wear-resistant, easy to move and easy to install. Industrial casters are easy to install. The wheels are made of top-grade polyurethane (PU), and the bracket is made of 2.5mm pickling plates to increase the reinforcement. The 3-inch casters can carry 150kg individually, and the treads are designed to enhance the anti-skid performance.

If you want buy fume extractor, please contact with Dongguan Pure-Air Tech Co.,ltd, E-mail: sales@pure-airtech.com.
