The integrated high quality fume extractor plus for laser, the composition of the filter cartridge dust collector has three overwhelming parts: the shell, the filter cartridge, and the dust removal system software.

(1) The housing is the housing of all dust collectors, including the dust collector and the silo. The dust collector is mainly to provide the needed ash removal indoor space, and the beneficial potential flow is effectively spread, and the silo is the raw material collected and filtered;

(2) The filter cartridge of integrated high quality fume extractor plus for soldering, high quality fume extractor plus- for laser soldering welding is composed of surface layer, inner layer and inner layer. The inner layer and the surface layer are metal wire mesh (or hard rubber mesh), and the center is a pleated filter material. The characteristic of the filter material for the filter cartridge is that a layer of sub-micron-level thin chemical fibers is adhered to the general filter material. The chemical fibers on the adhesive layer are closely ordered, and the gap is 0.12 ~ 0.6μm. Intensive expansion and contraction greatly increases the total area of filtering. The huge filtering range is the obvious characteristic of the filter cartridge;

(3) The ash cleaning system software specifically includes injection boiler blowpipe, pulse valve, air bag, etc. When the area of the filter cartridge has a certain thickness, it is necessary to carry out dust removal. The smoke and dust cyclone is filtered through the filter cartridge and then discharged. When the friction resistance of the dust collector reaches the preset value of the pressure difference or the preset value of the time, the pressure difference manipulator or the time manipulator controls the corresponding relay to open the position. In the closed mode of the pulse valve, air compression is immediately sprayed to the core of the filter cartridge to carry out a single pulse cleaning.

If you want buy fume extractor, please contact with Dongguan Pure-Air Tech Co.,ltd, E-mail: sales@pure-airtech.com.
