Fixed welding fume purifier multi-station, high requirements for welding point location, welding fume treatment method saves investment, adopts centralized collection tube to achieve purification efficiency, and make the room clean and beautiful.

The welding fume purification device operates in multiple stations and is also called a centralized vacuum cleaner. When laying pipes in the factory, each welding source is equipped with suction arms or gas hoods to facilitate the absorption of dust sources.

The collection hood is suitable for welding fume purification operations at large sites, and it is easy to collect welding fume at fixed sites

The air inlet arm is suitable for welding fume purification in small stations, and the angle and position of the air inlet arm can be flexibly adjusted to meet the needs of welding fume collection. Suitable for occasions with flexible solder joints.

Stationary welding fume purification system, also known as Centralized welding fume purification system, is a welding fume purification system suitable for many site conditions. The centralized welding fume purification system has good practicability, can meet the needs of welding fume purification in most cases, has a beautiful structure and saves space.

The welding dust removal system consists of dust removal fan, dust remover, control system, dust removal pipe, dust remover, dust remover operating parts and so on.

According to the customer's site conditions, determine the model of the dust suction fan and the purification host, including the diameter and length of the dust suction pipe; the number of systems; the physical and chemical properties of the dust collection; the host and system environment and other factors.

On-site smoke and dust are collected instantaneously by a fixed Welding fume purifier collector. The main pipe enters the dust collector with a gradually changing pipe diameter (to balance the wind speed and air volume at the end of the pipe). The smoke and dust are cut and purified by the high-efficiency purification filter in the collector. Attached to the outside of the filter, the pulse valve is under the control of the controller, and the system filter automatically blows back the dust from the inside to the outside at regular intervals. During the back blow process, the particles fall into the ash hopper to collect, and the ash hopper accumulates to a certain extent. The amount of particulate matter needs to be transported out of the country. Through the action of the fan, the purified standard gas is discharged from the chimney.

If you want buy fume extractor, please contact with Dongguan Pure-Air Tech Co.,ltd, E-mail: sales@pure-airtech.com.
