Pure-Air professional single pulse cartridge dust collector and cartridge dust collector equipment.

The quality of pulse compressed air is a fatal key to the performance of Single pulse cartridge dust collector and cartridge dust collector equipment. It directly affects the dust removal effect of the dust collector and the normal operation of the system. In the design of the dust removal system, the compressed air sent from the factory must be further processed before it can be used. This design is aimed at the processing of pulsed air sources, and considers adding a set of freeze dryers and a heating set between the air storage tank and the intermediate air bag. Air bag, dehumidification, degreasing and heating treatment of the pulse air source to ensure the dryness and purity of the air source and temperature during pulse injection, effectively preventing the clogging of the bag and the phenomenon of condensation and compaction, and improving the dust removal of the dust collector The effect and the life of the cloth bag, the specific processing process is as follows: factory air source-air bag-coarse filter-freeze dryer-fine filter-decompression-heating air bag-each warehouse is divided into air bag (using Preheating by heat of the flue gas)-blowing by the injection valve.

Because the domestic similar Single pulse cartridge dust collector and cartridge dust collector equipment often neglect the treatment of the air source in the use, it leads to undesirable consequences such as condensation and compaction of the cloth bag and high resistance of the dust collector. The formation of condensation comes from two aspects:

1) The gas source contains a lot of water and oil, especially in summer, it is more likely to cause hardening;

2) The cold air flow formed by the high-speed jet of the air source and the hot air flow in the bag form a temperature difference, which is easy to condense, especially in the rainy weather or the alpine season with high air humidity.

●The heating air bag, according to the pulse gas volume of 0.25~0.3m3/time and every 10s~15s, the heating power is calculated with the pulse width of 0.1 second each time. At the same time, considering the use of the flue gas operating temperature of the dust collector to heat the pulse air bag to ensure the effect of the air source treatment.

●Remote pressure and temperature display, monitor the heating air bag temperature and outlet pressure, and observe the fluctuation range. The heating air bag adopts 8 groups of heating elements, 4 temperature measuring points, and uses the on-off frequency to ensure a constant temperature of ~50-60℃. After exceeding the upper limit of temperature, the heater will be automatically cut off and alarm. At the same time, monitor the injection pressure to make the actual working injection pressure reach 0.25-0.3MPa.

If you want to buy high quality fume extractor for different industry, please contact with ‘Dongguan Pure-Air Tech Co.,Ltd.’.
